Remote Master Cylinder Reservoir Kit

Description

If your race car has a floor mounted master cylinder, you’ve likely experienced issues from stepping on the attached plastic reservoir or spilling brake fluid in the car when servicing. The Remote Master Cylinder Reservoir Kit (TMR-1243K-R) was designed to resolve these issues by removing the standard plastic tank and replacing it with a low profile connection to an external reservoir that can be placed in a secure and accessible location.

Compatible with Mopar style master cylinders, the kit utilizes a low profile billet adapter that directly replaces the standard plastic tank attached to the top of a master cylinder.

Replacing the standard tank is a billet reservoir which can be mounted easily in a safe and accessible location with the included 4130 tab and bottle mount kit. The 6061 aluminum dual remote reservoir is more resistant to heat damage than plastic reservoirs and utilizes separate internal chambers for front and rear systems. While a threaded cap insures a tight seal, an internal diaphragm allows for fluid displacement. Clear anodized for corrosion resistance, the billet reservoir also features external markings to reference fluid levels.

The Remote Master Cylinder Reservoir Kit gives you everything needed to create an external fluid storage system including 12’ of stainless P.T.F.E. lined hose and premium fittings.

*Works with Mopar style master cylinders such as Wilwood (WIW-260-4894) and Lamb.

Check out the short video below to learn more about the advantages of this system.
